| 122A.02.01-1 | 防水开关 | Waterproof switch |
| 122A.02.02 | 管子 | Pipe |
| 122A.02.04-1 | 水管 | Water pipe |
| 122A.02.001 | 加温器进水管 | Inlet pipe of the heater |
| 122A.02.002 | 水管 | Water pipe |
| 122A.02.007 | 管子 | Pipe |
| 122A.02.008 | 弹簧 | Spring |
| 122A.02.009 | 弹簧筒 | Spring cylinder |
| 122A.02.011 | 螺钉 | Screw |
| 122A.02.014 | 管子 | Pipe |
| 122.02.01 | 水散热器 | Water radiator |
| 122.02.02 | 风扇 | Fan |
| 122.02.03 | 管总成 | Pipe assembly |
| 122.02.04 | 加热器接通开关 | Heater connection switch |
| 122.02.05 | 水管 | Water pipe |
| 122.02.06 | 水管 | Water pipe |
| 122.02.11 | 三通管 | Three-way pipe |
| 122.02.12 | 加热器出气管 | Outlet pipe of the heater |
| 122.02.13-3B | 散热器右护板 | Right guard plate of the radiator |
| 122.02.14-5 | 散热器下护板 | Lower guard plate of the radiator |
| 122.02.16 | 前集水器 | Front water collector |
| 122.02.17 | 后集水器 | Rear water collector |
| 122.02.18 | 护板 | Guard plate |
| 122.02.21 | 连接管 | Connecting pipe |
| 122.02.23 | 管子 | Pipe |
| 122.02.57-1 | 散热器后侧小护板 | Rear side guard plate |
| 122.02.004 | 水管 | Water pipe |
| 122.02.012 | 旋转接头 | Rotary joint |
| 122.02.013 | 空心螺栓 | Hollow bolt |
| 122.02.019 | 管子 | Pipe |
| 122.02.024 | 钢性弹垫 | Rigid spring pad |
| 122.02.025 | 钢性弹垫 | Rigid spring pad |
| 122.02.036 | 密封护板 | Sealing guard plate |
| 122.02.037 | 密封护板 | Sealing guard plate |
| 122.02.038 | 密封板 | Sealplate |
| 122.02.040 | 水管 | Water pipe |
| 122.02.041 | 水管 | Water pipe |
| 122.02.042 | 水管 | Water pipe |
| 122.02.043 | 水管 | Water pipe |
| 122.02.044 | 水管 | Water pipe |
| 122.02.045 | 水管 | Water pipe |
| 122.02.047 | 管子 | Pipe |
| 122.02.051 | 管子 | Pipe |
| 122.02.052 | 管子 | Pipe |
| 122.02.053 | 水管 | Water pipe |
| 122.02.054 | 管子 | Pipe |
| 122.02.061 | 散热器扭杆 | Radiator torsion rod |
| 122.03.01 | 机油箱 | Sump |
| 122.03.02 | 机油散热器 | Oil radiator |
| 122.03.03 | 双层油管 | Double-layer oil pipe |
| 122.03.04 | 油管 | Oil pipe |
| 122.03.05 | 油管 | Oil pipe |
| 122.03.06 | 机油散热器前护板 | Front guard plate |
| 122.03.07 | 机油散热器后护板 | Car rear trunk security shield |
| 122.03.08 | 油管 | Oil pipe |
| 122.03.09 | 通气管 | Breather pipe |
| 122.03.10-1 | 机油泵进油转接管 | Oil inlet transfer pipe |
| 122.03.11 | 接管 | Take over |
| 122.03.17 | 循环机油箱 | Circulating machine oil tank |
| 122.03.18 | 导管 | Catheter |
| 122.03.22 | 机油散热器左护板 | Left guard plate of the oil radiator |
| 122.03.002 | 通气管 | Breather pipe |
| 122.03.006 | 弹簧 | Spring |
| 122.03.025 | 衬垫 | Padding |
| 122.03.026 | 衬垫 | Padding |
| 122.03.031 | 集油器 | Oil collector |
| 122.03.051 | 通气管 | Breather pipe |
| 122.04.01 | 空气滤清器 | Air filter |
| 122.04F2.01 | 空气滤清器 | Air filter |
| 122.04.02 | 前阀门 | Front valve |
| 122.04.03 | 后阀门 | Rear valve |
| 122.04.05 | 卡箍 | Clamp |
| 122A.04.06 | 卡箍带 | Clamp band |
| 122.04.07 | 前一级滤 | Pre-stage filtration |
| 122.04.08 | 头部总成 | Head assembly |
| 122.04.09 | 后一级滤 | The second-level filter |
| 122.04.11 | 细滤尘盒 | Fine dust filter box |
| 122.04.12 | 粗滤尘盒 | Coarse dust filter box |
| 122.04.010 | 压圈 | Pressure ring |
| 122.04.007 | 压板 | Pressure plate |
| 122.04.013 | 螺栓 | Bolt |
| 122.04.017 | 螺杆 | Screw |
| 122.04.018-1 | 旋风筒 | Cyclone cylinder |
| 122.04.018-1/019-1 | 旋风筒/导流管 | Cyclone cylinder/deflector tube |
| 122.04.020 | 上格状板 | Upper grid plate |
| 122.04.019/020 | 导流管/上格状板 | Guide pipe/upper grid-shaped plate |
| 122.04.027 | 连接盘 | Connecting disk |
| 122.04.028 | 连接盘 | Connecting disk |
| 122.04.031 | 压板 | Pressure plate |
| 122.04.033 | 压板 | Pressure plate |
| 122.04.059 | 销轴 | Hinge pin |
| 122E.04.01 | 空气滤清器 | Air filter |
| 122E.04.02-1 | 前密封挡板 | Front sealing baffle |
| 122E.04.03 | 后密封挡板 | Rear sealing baffle |
| 122E.04.06 | 连接管 | Connecting pipe |
| 122A.05.01 | 气管 | Air tube |
| 122A.05.02 | 卡带 | Cassette tape |
| 122A.05.03 | 油管 | Oil pipe |
| 122A.05.04 | 油管 | Oil pipe |
| 122A.05.12 | 柴油注油箱 | Diesel fuel tank |
| 122A.05.13 | 右弹架油箱 | Right bomb rack fuel tank |
| 122A.05.14-1 | 气管 | Air tube |
| 122A.05.15 | 油管 | Oil pipe |
| 122A.05.17 | 小油箱 | Small fuel tank |
| 122A.05.22 | 油管 | Oil pipe |
| 122A.05.27 | 管接头 | Pipe joint |
| 122A.05.001 | 气管 | Air tube |
| 122A.05.010 | 油管 | Oil pipe |
| 122A.05.023 | 拉紧螺栓 | Draw-in bolt |
| 122A.05.024 | 销轴 | Hinge pin |
| 122A.05.044 | 空心螺栓 | Hollow bolt |
| 122A.05.056 | 放油螺塞 | Oil drain plug |
| 122A.05.065 | 紧固螺母 | Tight nut |
| 122.05.01 | 左前柴油箱 | Left front diesel tank |
| 122.05.02 | 右前柴油箱 | Right front diesel tank |
| 122.05.04 | 左弹架油箱 | Left ammunition rack fuel tank |
| 122.05.11 | 油面指示器 | Oil level indicator |
| 122.05.13 | 长卡带 | Long cassette tape |
| 122.05.14 | 油面指示器开关 | Oil level indicator switch |
